Demo Questions

Question 1
A network administrator is implementing a configuration plan in NetEdit. The administrator used NetEdit to push the configuration plan to the switch. Which option in the NetEdit planning section should the administrator select to save the configuration running on the switch to the startup-config?
  1. EDIT
  2. VALIDATE
  3. COMMIT
  4. DEPLOY
Correct answer: C
Question 2
Which statement is correct regarding ACLs and TCAM usage?
  1. Applying an ACL to a group of ports consumes the same resources as specific ACE entries
  2. Using object groups consumes the same resources as specific ACE entries
  3. Compression is automatically enabled for ASIC TCAMs on AOS-CX switches
  4. Applying an ACL to a group of VLANs consumes the same resources as specific ACE entries
Correct answer: B
Question 3
What is correct regarding rate limiting and egress queue shaping on AOS-CX switches?
  1. Only a traffic rate and burst size can be defined for a queue
  2. Limits can be defined only for broadcast and multicast traffic
  3. Rate limiting and egress queue shaping can be used to restrict inbound traffic
  4. Rate limiting and egress queue shaping can be applied globally
Correct answer: A
Question 4
A network administrator needs to replace an antiquated access layer solution with a modular solution involving AOS-CX switches. The administrator wants to leverage virtual switching technologies. The solution needs to support high-availability with dual-control planes.
Which solution should the administrator implement?
  1. AOS-CX 8325
  2. AOS-CX 6300
  3. AOS-CX 6400
  4. AOS-CX 8400
Correct answer: C
Explanation:
Reference:https://andovercg.com/datasheets/aruba-cx-8325-switch-series.pdf
Reference:
https://andovercg.com/datasheets/aruba-cx-8325-switch-series.pdf
Question 5
A company has implemented 802.1X authentication on AOS-CX access switches, where two ClearPass servers are used to implement AAA.
Each switch has the two servers defined. A network engineer notices the following command configured on the AOS-CX switches: radius-server tracking user-name monitor password plaintext aruba123 What is thepurpose of this configuration?
  1. Implement replay protection for AAA messages
  2. Define the account to implement downloadable user roles
  3. Speed up the AAA authentication process
  4. Define the account to implement change of authorization
Correct answer: C
Explanation:
Radius service tracking locates the availability of the RADIUS service configured on the switch. It helps to minimize the waiting period for new clients in the unauth-vid (Guest Vlan) when authentication fails because of service is not available, as well as previously authenticated clients in unauth-vid (Guest Vlan) when re-authentication fails because service is not available during the reauthentication period. Note that this feature is disabled by default.https://techhub.hpe.com/eginfolib/networking/docs/switches/WB/16-02/5200-1650_WB_ASG/content/ch04s04.html
Radius service tracking locates the availability of the RADIUS service configured on the switch. It helps to minimize the waiting period for new clients in the unauth-vid (Guest Vlan) when authentication fails because of service is not available, as well as previously authenticated clients in unauth-vid (Guest Vlan) when re-authentication fails because service is not available during the reauthentication period. Note that this feature is disabled by default.
https://techhub.hpe.com/eginfolib/networking/docs/switches/WB/16-02/5200-1650_WB_ASG/content/ch04s04.html
Question 6
A company has an existing wireless solution involving Aruba APs and Mobility controllers running 8.4 code.
The solution leverages a third-party AAA solution. The company is replacing existing access switches with AOS-CX 6300 and 6400 switches. The company wants to leverage the same security and firewall policies for both wired and wireless traffic.
Which solution should the company implement?
  1. RADIUS dynamic authorization
  2. Downloadable user roles
  3. IPSec
  4. User-based tunneling
Correct answer: D
Question 7
A network engineer is having a problem adding a custom-written script to an AOS-CX switch's NAE GUI. The script was written in Python and was successfully added on other AOS-CX switches. The engineer examines the following items from the CLI of the switch:
What should the engineer perform to fix this issue?
  1. Install the script's signature before installing the new script
  2. Ensure the engineer's desktop and the AOS-CX switch are synchronized to the same NTP server
  3. Enable trust settings for the AOS-CX switch's SSL certificate
  4. Remove a script that is no longer used before installing the new script
Correct answer: D
Question 8
Which option correctly defines how to identify a VLAN as a voice VLAN on an AOS-CX switch?
  1. Switch(config)# port-access lldp-group <LLDP-group-name>
    Switch(config-lldp-group)# vlan <VLAN-ID>
  2. Switch(config)# port-access role <role-name>
    Switch(config-pa-role)# vlan access <VLAN-ID>
  3. Switch(config)# vlan <VLAN-ID>
    Switch(config-vlan-<VLAN-ID>)# voice
  4. Switch(config)# vlan <VLAN-ID> voice
Correct answer: C
Question 9
An administrator will be replacing a campus switching infrastructure with AOS-CX switches that support VSX capabilities. The campus involves a core, as well as multiple access layers. Which feature should the administrator implement to allow both VSX-capable core switches to process traffic sent to the default gateway in the campus VLANs?
  1. VRF
  2. VRRP
  3. IP helper
  4. Active gateway
Correct answer: D
Explanation:
Active gateway = both devices route/forward traffic VRRP = Active-standbye, only active member routes/forwards traffic Understand the Active Gateway principle In a VSX system, active gateway provides redundant default gateway functionality for the end-hosts. The default gateway of the end-host is automatically handled by both the VSX systems.
Active gateway = both devices route/forward traffic VRRP = Active-standbye, only active member routes/forwards traffic Understand the Active Gateway principle In a VSX system, active gateway provides redundant default gateway functionality for the end-hosts. The default gateway of the end-host is automatically handled by both the VSX systems.
Question 10
What is correct regarding the tunneling of user traffic between AOS-CX switches and Aruba Mobility Controllers (MCs)?
  1. Uses IPSec to protect the management and data traffic
  2. Uses IPSec to protect the management traffic
  3. Supports only port-based tunneling
  4. Uses the same management protocol as Aruba APs
Correct answer: D
